Project Name: Start Project – Basic Module Tests

Version: 0.1 Description: Simple start project to test all onboard modules:

• TFT Display, BMP280, QMI8658C, RGB-LED
• Select „ESP32S3 Dev Module" in the Arduino Board Manager.
• Ensure all required libraries are installed.

Hardware: ESP32-S3 FH4R2, 1.14" TFT Display, BMP280, QMI8658C, WS2812 RGB-LED

Initial Setup: To enter boot mode and program your ESP32S2:

1. Connect the ESP32S3 via USB.
2. Hold the "BOOT" button.
3. While holding "BOOT", press and release the "RST" button.
4. Release "BOOT".

Warning: The RGB LED and QMI8658C sensor cannot be used simultaneously when connected to GPIO33, due to a conflict in the QMI library.

Setting up Arduino IDE for the Tenstar Robot ESP32S3-1.14TFTBoard (SENSATE-X BIP) - file

Startsketch.ino
